Specifications
ZAY7025FG
ZAY7032FG
ZAY7040FG
ZAY7045FG
Max. drilling capacity
25mm
32mm
40mm
45mm
Max. face milling capacity
63mm
80mm
Max. end milling capacity
20mm
Max. distance from spindle nose to table surface
445mm
450mm
Min. distance from spindle axis to column surface
203mm
260mm
Spindle travel
85mm
130mm
Spindle taper
MT3 or R8
MT4 or R8
Spindle speed step
6
Spindle speed 50Hz
95-1420rpm
80-1250rpm
Spindle speed 60Hz
115-1700rpm
95-1500rpm
Swivel angle of headstock (vertical)
±90°
Table size
520x160mm
800x240mm
X-axis travel
290mm
500mm
Y-axis travel
140mm
175mm
Main motor
0.37kW (0.5HP)
0.75kW (1HP)
1.1kW (1.5HP)
1.5kW (2HP)
N.W./G.W.
180/240kg
320/370kg
323/373kg
325/375kg
Packing size
680x750x1000mm
770x880x1160mm
Standard Accessories
Optional Accessories
Allen wrench
Drill chuck
Wedge
Milling cutter holder
Drawbar
Milling chuck
Power feed
Auto tapping function
Machine vice
Work light
Coolant system
Machine stand
Chip tray
Clamping kit
Rotary table
DRO
