Specifications
ZAY7032FG/1
ZAY7040FG/1
ZAY7045FG/1
Max. drilling capacity
32mm
40mm
45mm
Max. boring capacity
50mm
60mm
70mm
Max. face milling capacity
63mm
80mm
Max. end milling capacity
20mm
Max. distance from spindle nose to table surface
450mm
Min. distance from spindle axis to column surface
260mm
Spindle travel
130mm
Spindle taper
MT3 or R8
MT4 or R8
Spindle speed step
6
Spindle speed 50Hz
80-1250rpm
Spindle speed 60Hz
95-1500rpm
Spindle auto feed step
Spindle auto feed
0.06-0.30mm/r
Swivel angle of headstock (vertical)
±90°
Spindle auto lift
240mm/min
Table power feed
Stepless
Table size
800x240mm
X-axis travel
500mm
Y-axis travel
175mm
Main motor
0.75kW (1HP)
1.1kW (1.5HP)
1.5kW (2HP)
N.W./G.W.
320/370kg
323/373kg
325/375kg
Packing size
770x880x1160mm
Standard Accessories
Optional Accessories
Allen wrench
Drill chuck
Wedge
Milling cutter holder
Drawbar
Milling chuck
Power feed
Auto tapping function
Machine vice
Work light
Coolant system
Machine stand
Chip tray
Clamping kit
Rotary table
DRO
